APD F112-N200/Y高壓DC/DC轉換器模塊
發布時間：2025-08-19 09:10:20 瀏覽：445
American Power Design, Inc. 的F1 系列微型穩壓高壓 DC/DC 轉換器提供 100%
可編程高壓輸出。輸出電壓監控器和板載精密基準是標準配置。所有型號都可以無限期地容忍短路。
型號：
| 5VDC INPUT MODELS |
| REPRESENTATIVE MODEL LISTING |
| MODEL NUMBER | INPUT CURRENT | OUTPUT SPECIFICATIONS |
| Non-RoHs | RoHs | NO
LOAD | FULL
LOAD | VOLTAGE | RIPPLE | CURRENT | REGULATION |
| LOAD | LINE |
| F15-P10 | F15-P10/Y | <65 mA | <420 mA | 0 to+100Vdc | <0.05%(50mV p-p) | 0-10mA | <0.05% | <0.01% |
| F15-N10 | F15-N10/Y | <65 mA | <420 mA | 0 to-100Vdc | <0.05%(50mV p-p) | 0-10mA | <0.05% | <0.01% |
| F15-P20 | F15-P20/Y | <65 mA | <420 mA | 0 to +200Vdc | <0.01%(10mVp-p) | 0-5mA | <0.01% | <0.01% |
| F15-N20 | F15-N20/Y | <65 mA | <420 mA | 0 to -200Vdc | <0.01%(10mVp-p) | 0-5mA | <0.005% | <0.003% |
| F15-P30 | F15-P30/Y | <65 mA | <420 mA | 0 to+300Vdc | <0.01%(30mV p-p) | 0-3.3mA | <0.005% | <0.003% |
| F15-N30 | F15-N30/Y | <65 mA | <420 mA | 0 to-300Vdc | <0.01%(30mVp-p) | 0-3.3mA | <0.005% | <0.003% |
| F15-P50 | F15-P50/Y | <65 mA | <420 mA | 0 to+500Vdc | <0.005%(25mVp-p) | 0-2mA | <0.003% | <0.002% |
| F15-N50 | F15-N50/Y | <65 mA | <420 mA | 0 to-500Vdc | <0.005%(25mVp-p) | 0-2mA | <0.005% | <0.002% |
| F15-P60 | F15-P60/Y | <65 mA | <420 mA | 0 to+600Vdc | <0.005%(30mVp-p) | 0-1.67mA | <0.005% | <0.002% |
| F15-N60 | F15-N60/Y | <65 mA | <420 mA | 0 to-600Vdc | <0.005%(30mVp-p) | 0-1.67mA | <0.005% | <0.002% |
| F15-P100 | F15-P100/Y | <65 mA | <420 mA | 0 to+1000Vdc | <0.001%(10mVp-p) | 0-1mA | <0.005% | <0.001% |
| F15-N100 | F15-N100/Y | <65 mA | <420 mA | 0 to-1000Vdc | <0.001%(10mVp-p) | 0-1mA | <0.005% | <0.001% |
| F15-P125 | F15-P125/Y | <65 mA | <420 mA | 0 to+1250Vdc | <0.001%(12mVp-p) | 0-0.8mA | <0.005% | <0.001% |
| F15-N125 | F15-N125/Y | <65 mA | <420 mA | 0 to-1250Vdc | <0.001%(12mVp-p) | 0-0.8mA | <0.005% | <0.001% |
| F15-P150 | F15-P150/Y | <155 mA | <550 mA | 0 to+1500Vdc | <0.001%(15mVp-p) | 0-0.67mA | <0.005% | <0.001% |
| F15-N150 | F15-N150/Y | <155 mA | <550 mA | 0 to-1500Vdc | <0.001%(15mVp-p) | 0-0.67mA | <0.005% | <0.001% |
| F15-P200 | F15-P200/Y | <155 mA | <550 mA | 0 to+2000Vdc | <0.001%(20mVp-p) | 0-0.5mA | <0.005% | <0.003% |
| F15-N200 | F15-N200/Y | <155 mA | <550 mA | 0 to-2000Vdc | <0.001%(20mVp-p) | 0-0.5 mA | <0.001% | <0.001% |
| 12VDC INPUT MODELS |
| REPRESENTATIVE MODEL LISTING |
| MODEL NUMBER | INPUT CURRENT | OUTPUT SPECIFICATIONS |
| Non-RoHs | RoHs | NO
LOAD | FULL
LOAD | VOLTAGE | RIPPLE | CURRENT | REGULATION |
| LOAD | LINE |
| F112-P10 | F112-P10/Y | <80 mA | <220 mA | 0 to+100Vdc | <0.05%(50mVp-p) | 0-10mA | <0.05% | <0.01% |
| F112-N10 | F112-N10/Y | <80 mA | <220 mA | 0 to-100Vdc | <0.05%(50mVp-p) | 0-10mA | <0.05% | <0.01% |
| F112-P20 | F112-P20/Y | <80 mA | <220 mA | 0 to+200Vdc | <0.01%(10mVp-p) | 0-5mA | <0.05% | <0.01% |
| F112-N20 | F112-N20/Y | <80 mA | <220 mA | 0 to -200Vdc | <0.01%(10mV p-P) | 0-5mA | <0.05% | <0.01% |
| F112-P30 | F112-P30/Y | <80 mA | <220 mA | 0 to +300Vdc | <0.01%(30mVp-p) | 0-3.3mA | <0.05% | <0.01% |
| F112-N30 | F112-N30/Y | <80 mA | <220 mA | 0 to-300Vdc | <0.01%(30mVp-p) | 0-3.3mA | <0.05% | <0.01% |
| F112-P50 | F112-P50/Y | <80 mA | <220 mA | 0 to+500Vdc | <0.01%(50mVp-p) | 0-2mA | <0.01% | <0.01% |
| F112-N50 | F112-N50/Y | <80 mA | <220 mA | 0 to-500Vdc | <0.01%(50mVp-p) | 0-2mA | <0.01% | <0.01% |
| F112-P60 | F112-P60/Y | <80 mA | <220 mA | 0 to+600Vdc | <0.01%(60mVp-p) | 0-1.67mA | <0.01% | <0.01% |
| F112-N60 | F112-N60/Y | <80 mA | <220 mA | 0 to -600Vdc | <0.01%(60mV p-p) | 0-1.67mA | <0.01% | <0.01% |
| F112-P100 | F112-P100/Y | <80 mA | <220 mA | 0 to+1000Vdc | <0.001%(10mVp-p) | 0-1mA | <0.005% | <0.001% |
| F112-N100 | F112-N100/Y | <80 mA | <220 mA | 0 to-1000Vdc | <0.001%(10mVp-p) | 0-1mA | <0.005% | <0.001% |
| F112-P125 | F112-P125/Y | <80 mA | <220 mA | 0 to+1250Vdc | <0.0005%(6mVp-p) | 0-0.8mA | <0.005% | <0.001% |
| F112-N125 | F112-N125/Y | <80 mA | <220 mA | 0 to-1250Vdc | <0.0005%(6mVp-p) | 0-0.8mA | <0.005% | <0.001% |
| F112-P150 | F112-P150/Y | <100 mA | <220 mA | 0 to+1500Vdc | <0.001%(15mVp-p) | 0-0.67mA | <0.01% | <0.01% |
| F112-N150 | F112-N150/Y | <100 mA | <220 mA | 0 to-1500Vdc | <0.001%(15mVp-p) | 0-0.67mA | <0.01% | <0.01% |
| F112-P200 | F112-P200/Y | <100 mA | <220 mA | 0 to +2000Vdc | <0.001%(20mVp-p) | 0-0.5mA | <0.01% | <0.01% |
| F112-N200 | F112-N200/Y | <100 mA | <220 mA | 0 to-2000Vdc | <0.001%(20mVp-p) | 0-0.5mA | <0.01% | <0.01% |
電氣規格
| 參數 | 5V輸入型號 | 12V輸入型號 |
| 輸入電壓范圍 | 4.75-5.25Vdc | 11.5-15.5Vdc |
| 滿載輸入電流（典型） | 420-550mA | 220mA |
| 輸出紋波（峰峰值） | <0.001% (10mV) | <0.001% (10mV) |
| 負載調整率 | <0.05% | <0.05% |
| 線性調整率 | <0.01% | <0.01% |
| 開關頻率 | 180-250kHz | 同左 |
核心特性
輸出范圍：±100V至±2000V可編程(客戶自定義)
精度：輸出電壓精度<1%，線性度<0.5%(5%~100%輸出范圍內)
穩定性：溫度穩定性<25ppm/°C，長期穩定性<50ppm/小時
保護功能：持續短路保護、反接保護(50V)、過壓編程保護(>104%時自動關閉)
可編程控制：通過0-2.048V/0-5V信號(阻抗100kΩ)實現0-100%輸出調節
監測接口：提供輸出電壓監控引腳(0-2.048V/0-5V對應0-100%輸出)
參考電壓：板載精密參考源(2.048V或5V@1mA)
物理與環境規格
尺寸：1.1×1.75×0.5英寸(28×44.5×12.7mm)，重量1.3盎司(37g)
材料：鎳鍍金屬外殼，UL 94V-0環氧樹脂封裝
工作溫度：-55°C至+85°C(存儲溫度-55°C至+95°C)
認證：IEC/UL/CSA/EN 62368 & CE
深圳市立維創展科技有限公司優勢代理銷售American Power Design(APD)高壓DC/DC轉換器產品，歡迎咨詢了解。
